Optical Endstop for 3D Printers

Enhance your 3D printing experience with our high-quality Optical Endstop, an essential component designed to provide precise control and reliable performance for your 3D printer. This optical control limit switch is engineered to deliver accurate positioning and eliminate mechanical wear, ensuring your printer operates at peak efficiency.

Product Overview

The Optical Endstop features an advanced optical switch mechanism that detects the presence of an object using infrared light, guaranteeing precise detection with minimal latency. This technology replaces traditional mechanical switches, enhancing both the accuracy and the longevity of your 3D printing setup. The Optical Endstop is packaged individually and comes equipped with a 50CM 3-pin cable, making it easy to install and integrate with your existing system.

Key Features

• High Precision: The optical detection eliminates the noisy clicking of mechanical switches, providing faster and more accurate responses.
• Durability: With no moving parts to wear down, the Optical Endstop ensures a long lifespan and reliable performance over time.
• Easy Installation: Equipped with a 50CM 3-pin cable, this endstop can be easily mounted and connected to your printer for quick setup.
• Compatibility: The Optical Endstop is designed to work seamlessly with most 3D printers, offering versatility and ease of integration with your existing devices.
• Consistent Performance: By using light to detect the end of the printing path, this optical endstop provides consistent and repeatable results, minimizing errors in your print jobs.

Specifications

Parameter	Details
Type	Optical Endstop
Input Voltage	5V
Cable Length	50CM
Connection	3-pin configuration
Operating Temperature	-40 to +85 °C

How It Works

The Optical Endstop operates by emitting an infrared light beam that is interrupted by the movement of the 3D printer's axis. When the light beam is blocked, the optical sensor detects this interruption and sends a signal to the printer's controller, indicating that the axis has reached its limit position. This system allows for smooth operation without the mechanical resistance of traditional switches, resulting in quieter and more efficient 3D printing.

Installation Instructions

1. Power off your 3D printer to prevent any accidental movements.
2. Locate the endstop mounting area on your printer frame.
3. Attach the Optical Endstop in the appropriate position using screws or mounting brackets, ensuring that the light emitter and sensor are aligned properly.
4. Connect the 50CM 3-pin cable to the corresponding input on your printer’s motherboard.
5. Power on the printer and test
