The Motherboard MakerBase MKS Monster8 V1.0 microcontroller board by MakerBase.
A Motherboard MakerBase MKS Monster8 V1.0 with a number of connectors on it, powered by an STM32F407VET6 microcontroller and equipped with 8-axis drivers.
A schematic diagram of a 3D printer Motherboard MakerBase MKS Monster8 V1.0 with an STM32F407VET6 microcontroller.

Motherboard MakerBase MKS Monster8 V1.0

  • Availability: in stock Many in stock Out of stock You can purchase this product but it's out of stock
  • Vendor: MakerBase
  • Description
  • Reviews

The MakerBase MKS Monster8 V1.0 is a high-end 3D printer motherboard. It features an STM32F407VET6 microcontroller with a 168MHz frequency, 512K flash, and 192KB RAM. The board supports 8-axis drivers and 9 motor interfaces, making it ideal for complex 3D printing projects. It's designed for a DC12-24V input and includes 4 heaters and temperature interfaces. The Monster8 V1.0 also offers 3 PWM fans, 3 power outputs, 6 endstops, a 4K EEPROM, and integrated SPI communication for microSD cards. Additional features include TMC UART and SPI mode support, driver power selection, TVS power spike protection, and power reverse connection protection. The board is compatible with Marlin 2.0.x and Klipper firmware.

Warning: Ensure you are knowledgeable about motherboard installations before purchasing the Mainboard. Always disconnect the power cable before starting the installation process. Incorrect installation can lead to serious issues, including damage to the printer.
